| Product composition | |
|---|---|
| Visible EO Camera |
1/1.8” sony IMX678 CMOS sensor 8.4Mega. 4K (3840 x 2160P) x32 Optical zoom/ x16 Digital zoom f=6.5~212mm , Autofocus, Defog. OnVif, RS-485, Pelco-D Protocol/VISCA. |
| LWIR Camera |
12um Uncooled 640 x 512 Fixed lens, x8 Digital zoom f=35mm, Autofocus OnVif, Pelco-D Protocol |
| Speed Dome Pan/Tilt |
Pan : 360˚endless Tilt : -110˚ ~+110˚ Accuracy : 0.25˚ Preset 255 / Tour 4 RS-422/485, Giga Ethernet |
| LED Illuminator |
IR LED (x2), 50m |
| System |
IP67, KC |
| Product composition | |
|---|---|
| Visible EO Camera |
1/1.8” sony IMX464 CMOS sensor 2Mega.(1920 x 1080P) x43 Optical zoom/ x32 Digital zoom f=15~650mm , Autofocus, Defog. OnVif, RS-485, Pelco-D Protocol/VISCA |
| LWIR Camera |
12um Uncooled 640 x 512 x3 Optical zoom / x4 Digital zoom f=25~75mm, Autofocus OnVif, Pelco-D Protocol |
| Pan/Tilt |
Pan : 360˚endless Tilt : -60˚ ~+30˚ Accuracy : 0.1˚ RS-422/485. |
| IR Illuminator |
IR 850nm, 240m(max.) CDS, RS232 |
| System |
IP66 |
| Product composition | |
|---|---|
| Visible EO Camera |
1/1.8” sony IMX464 CMOS sensor 4Mega.(2712 x 1538P) x43 Optical zoom/ x32 Digital zoom f=6.5~260mm , Autofocus, Defog. OnVif, RS-485, Pelco-D Protocol/VISCA |
| LWIR Camera |
12um Uncooled 640 x 512 x9 Optical zoom / x8 Digital zoom f=25~225mm, Autofocus OnVif, Pelco-D Protocol |
| Pan/Tilt |
Pan : 360˚endless Tilt : -60˚ ~+30˚ Accuracy : 0.005˚ RS-422/485. |
| Laser Illuminator |
808nm, 3~5km(max.), 0.8˚~ 70˚Continuous RS485, Pelco-D |
| System |
IP66, KC |
| Product composition | |
|---|---|
| Visible EO Camera |
1/1.1” sony IMX565 CMOS sensor 8Mega.(4K, 3840 x 2160P) x7 Optical zoom/ x16 Digital zoom f=60~420mm , Autofocus, Defog. OnVif, RS-485, Pelco-D Protocol/VISCA |
| SWIR Camera |
½” InGaAs SWIR Sensor 5um Uncooled HD(1280 x 1024P) x40 Optical zoom / x32 Digital zoom f=15.2~610mm, Autofocus OnVif, Pelco-D Protocol / VISCA |
| Pan/Tilt |
Pan : 360˚endless Tilt : -60˚ ~+30˚ Accuracy : 0.005˚ RS-422/485. |
| GPS |
Frequency : 1575.42 ~ 1608 MHz |
| LRF |
Laser safety(635nm)-1(Eye safe) Ranging capability : 50-32km RS422 |
| System |
IP66, KC |
| Product composition | |
|---|---|
| Visible EO Camera |
1/1.8” sony IMX464 CMOS sensor 4.2Mega.(2560 x 1440P) x42 Optical zoom/ x16 Digital zoom f=6.5~273mm , Autofocus, Defog. OnVif, RS-485, Pelco-D Protocol/VISCA |
| LWIR Camera |
12um Uncooled 640 x 512 Fixed lens Optical zoom / x4 Digital zoom f=100mm, Autofocus OnVif, Pelco-D Protocol |
| Pan/Tilt |
Pan : 360˚endless Tilt : -60˚ ~+30˚ Accuracy : 0.005˚ RS-422/485. |
| High Power Direction Speaker |
Peak output-150dB(max.) SPL@1M Communication Range- 1.5km Frequency Response-200Hz to 9KhZ Max.Power-400W Sound Projection-±15° at 2kHz/-5dB IP67 |
| System |
IP66, KC |
